| Place of Origin: | China,GuangDong |
| Brand Name: | Analog Devices Inc. |
| Certification: | ISO9001 |
| Model Number: | LTC6404HUD-4#TRPBF |
| Minimum Order Quantity: | >=10pcs |
|---|---|
| Price: | $4.9 |
| Packaging Details: | Original factory sealed packing with standard types: tube,tray,tape and reel,box,bag packing. Or request for your need. |
| Delivery Time: | 2-3work days |
| Payment Terms: | T/T, D/A, L/C, D/P, Western Union, MoneyGram |
| Supply Ability: | 20000 Acre/Acres per Day+pcs+2-3days |
| Description: | IC ADC DRIVER 16QFN | Package / Case: | 16-WFQFN Exposed Pad |
|---|---|---|---|
| Mounting Type: | Surface Mount | Operating Temperature: | -40°C ~ 85°C |
| Applications: | Data Acquisition | Type: | ADC Driver |
| Product Status: | Active | Base Product Number: | LTC6404 |
PRODUCT DESCRIPTION
The LTC®6404 is a family of AC precision, very low noise, low distortion, fully differential input/output amplifi ers optimized for 3V, single supply operation. The LTC6404-1 is unity-gain stable. The LTC6404-2 is designed for closed-loop gains greater than or equal to 2V/V.
The LTC6404-4 is designed for closed-loop gains greater than or equal to 4V/V. The LTC6404 closed-loop bandwidth extends from DC to 600MHz. In addition to the normal unfi ltered outputs (OUT+ and OUT–), the LTC6404 has a built-in 88.5MHz differential single-pole lowpass fi lter and an additional pair of fi ltered outputs (OUTF+, OUTF–).
An input referred voltage noise of 1.5nV/√Hz make the LTC6404 able to drive state-of-the-art 16-/18-bit ADCs while operating on the same supply voltage, saving system cost and power.
The LTC6404 is characterized, and maintains its performance for supplies as low as 2.7V and can operate on supplies up to 5.25V. It draws only 27.3mA, and has a hardware shutdown feature which reduces current consumption to 250μA.
The LTC6404 family is available in a compact 3mm × 3mm 16-pin leadless QFN package and operates over a –40°C to 125°C temperature range.
PRODUCT PROPERTIES
Product Status | Active |
Type | ADC Driver |
Applications | Data Acquisition |
Mounting Type | Surface Mount |
Package / Case | 16-WFQFN Exposed Pad |
Supplier Device Package | 16-QFN (3x3) |
Base Product Number | LTC6404 |
