STJK(HK) ELECTRONICS CO.,LIMITED
Quality first, reputation first, service first, customers first.
 |
| Place of Origin: | China,GuangDong,ShenZhen |
| Brand Name: | Analog Devices Inc. |
| Certification: | ISO9001 |
| Model Number: | LT1495CS8#TRPBF |
| Minimum Order Quantity: | >=20pcs |
|---|---|
| Price: | ￥1.69 |
| Packaging Details: | Original factory sealed packing with standard types: tube,tray,tape and reel,box,bag packing. Or request for your need. |
| Delivery Time: | 2-4days |
| Payment Terms: | T/T, Western Union, D/P, D/A, MoneyGram, L/C |
| Supply Ability: | 30000 Acre/Acres per Day+pcs+2-3days |
| Description: | IC OPAMP GP 2 CIRCUIT 8SO | Operating Voltage:: | 2.2V ~ 36 V |
|---|---|---|---|
| Operating Temperature:: | 0°C ~ 70°C | Product Status: | Active |
| -3db Bandwidth: | 2.7 KHz | Type: | Rail-to-Rail |
| Package / Case: | 8-SOIC | Base Product Number: | LT1495 |
PRODUCT DESCRIPTION
The LT® 1494/LT1495/LT1496 are the lowest power (IS ≤ 1.5µA) op amps with precision specifications. The extremely low supply current is combined with excellent amplifier specifications: input offset voltage is 375µV maximum with a typical drift of only 0.4µV/°C, input offset current is 100pA maximum.
A minimum open-loop gain (AVOL) of 100V/mV ensures that gain errors are small. The device characteristics change little over the supply range of 2.2V to ±15V. Supply rejection is 90dB and the common mode rejection ratio is 90dB. Operation is specified for 3V, 5V and ±15V supplies. Reverse battery protection (–18V␣ min) and inputs that operate above the positive supply make the LT1494/LT1495/LT1496 easy to use in harsh environments.
The low bias currents and offset current of the amplifier permit the use of megohm level source resistors without introducing significant errors. Voltage noise at 4µVP-P is remarkably low considering the low supply current. The LT1494 is available in the 8-Pin MSOP, PDIP and SO packages.The LT1495 is available in plastic 8-Pin PDIP and SO packages with the standard dual op amp pinout. The LT1496 is available in 14-Pin SO and PDIP packages.
PRODUCT PROPERTIES
|
Product Status
|
Active
|
|
Amplifier Type
|
General Purpose
|
|
Number of Circuits
|
2
|
|
Output Type
|
Rail-to-Rail
|
|
Slew Rate
|
0.001V/µs
|
|
Gain Bandwidth Product
|
2.7 kHz |
|
Current - Input Bias
|
250 pA
|
|
Voltage - Input Offset
|
200 µV
|
|
Current - Supply
|
1µA (x2 Channels)
|
|
Current - Output / Channel
|
1.5 mA
|
|
Voltage - Supply Span (Min)
|
2.2 V
|
|
Voltage - Supply Span (Max)
|
36 V
|
|
Operating Temperature
|
0°C ~ 70°C
|
|
Mounting Type
|
Surface Mount
|
|
Package / Case
|
8-SOIC (0.154", 3.90mm Width)
|
|
Supplier Device Package
|
8-SO
|
|
Base Product Number
|
LT1495
|
