| Place of Origin: | China,GuangDong,ShenZhen |
| Brand Name: | Analog Devices Inc. |
| Certification: | ISO9001 |
| Model Number: | LT6236CS6#TRMPBF |
| Minimum Order Quantity: | >=10pcs |
|---|---|
| Price: | ￥2.19 |
| Packaging Details: | Tape & Reel (TR) Cut Tape (CT) Digi-Reel |
| Delivery Time: | 2-4work days |
| Payment Terms: | T/T, D/A, L/C, D/P, Western Union, MoneyGram |
| Supply Ability: | 30000 Acre/Acres per Day+pcs+2-3days |
| Description: | IC OPAMP GP 1 CIRCUIT TSOT23-6 | Operating Voltage:: | 3V~ 12.6 V |
|---|---|---|---|
| Operating Temperature:: | 0°C ~ 70°C | Product Status: | Active |
| -3db Bandwidth: | 90 MHz | Type: | Zero-Drift |
| Package / Case: | TSOT-23-6 | Base Product Number: | LT6236 |
PRODUCT DESCRIPTION
The LT®6236/LT6237/LT6238 are single/dual/quad low noise, rail-to-rail output op amps that feature 1.1nV/√Hz input referred noise voltage density and draw only 3.5mA of supply current per amplifier.
These amplifiers combine very low noise and supply current with a 215MHz gain bandwidth product and a 70V/µs slew rate. Low noise, fast settling time and low offset voltage make this amplifier optimal to drive low noise, high speed SAR ADCs. The LT6236 includes a shutdown feature that can be used to reduce the supply current to less than 10µA.
This amplifier family has an output that swings within 50mV of either supply rail to maximize the signal dynamic range in low supply applications and is specified on 3.3V, 5V and ±5V supplies. The LT6236/LT6237/LT6238 are upgrades to the LT6230/ LT6231/LT6232, offering similar performance with reduced wideband noise beyond 100kHz.
PRODUCT PROPERTIES
|
Product Status
|
Active
|
|
Amplifier Type
|
General Purpose
|
|
Number of Circuits
|
1
|
|
Output Type
|
Rail-to-Rail
|
|
Slew Rate
|
70V/µs
|
|
Gain Bandwidth Product
|
215 MHz
|
|
-3db Bandwidth
|
90 MHz
|
|
Current - Input Bias
|
5 µA
|
|
Voltage - Input Offset
|
100 µV
|
|
Current - Supply
|
3.3mA
|
|
Voltage - Supply Span (Min)
|
3 V
|
|
Voltage - Supply Span (Max)
|
12.6 V
|
|
Operating Temperature
|
0°C ~ 70°C
|
|
Mounting Type
|
Surface Mount
|
|
Package / Case
|
SOT-23-6 Thin, TSOT-23-6
|
|
Supplier Device Package
|
TSOT-23-6
|
|
Base Product Number
|
LT6236
|
