LM2902YPT Operational amplifier-operational amplifier Low power, bipolar op-amp

Manufacturer: STMicroelectronics
Product category: operational amplifier-operational amplifier
Number of channels: 4 Channel
GBP- Gain Bandwidth Product: 1.3 MHz
SR-conversion rate: 400 mV/us
Vos-input bias voltage: 7 mV
Ib-input bias current: 150 nA
Power supply voltage-max: 30 V, +/- 15 V
Power supply voltage-3 V minimum,+/-1.5 V.
Operating power supply current: 1.5 mA
Output current per channel: 40 mA
CMRR-common mode rejection ratio: 80 dB
En-noise density of input voltage: 40 nV/sqrt Hz
Package/box: TSSOP-14
Installation style: SMD/SMT
Close: No Shutdown
Minimum operating temperature:-40 C.
Maximum operating temperature:+125c
Series: LM2902
Qualification: AEC-Q100
Package: Reel
Package: cuttape
Encapsulation: MouseReel
Amplifier type: Low Power Amplifier
Trademark: STMicroelectronics
Dual power supply voltages:+/-3 V,+/-5 V,+/-9 V,+/-12 V.
Height: 1 mm
Length: 5 mm
Maximum dual supply voltage:+/-15 V.
Minimum dual supply voltage:+/-1.5 V.
Working power supply voltage: 5 V, 9 V, 12 V, 15 V
Product type: Opamps-operational amplifiers
Subcategory: Amplifier ICs
Power supply type: Single, Dual
Technology: biped
Voltage gain dB: 100 dB
Width: 4.4 mm
Unit weight: 140.300mg.
