| Detailed Description: | LED Driver IC 1 Output DC DC Controller Step-Up (Boost) PWM Dimming 50mA 24-QFN | Topology: | Step-Up (Boost) |
|---|---|---|---|
| Applications: | Automotive | Voltage - Output: | 5V ~ 30V |
| Operating Temperature:: | -40°C ~ 150°C (TJ) | Product Status: | Active |
| Package / Case: | 24-VFQFN Exposed Pad | Base Product Number: | NCV78702 |
| D/C: | 21+22+23+ |
PRODUCT DESCRIPTION
The NCV78702 is a single−chip and high efficient booster for smart Power ballast and LED Driver designed for automotive front lighting applications like high beam, low beam, DRL (daytime running light), turn indicator, fog light, static cornering, etc. The NCV78702 is in particular designed for high current LEDs and with NCV78723 (dual channel buck)/713 (single channel) provides a complete solution to drive multiple LED strings of up−to 60 V.
It includes a current−mode voltage boost controller which also acts as an input filter with a minimum of external components. The available output voltage can be customized. Two devices NCV78702 can be combined and the booster circuits can operate together to function as a multiphase booster (2−phase, 3−phase, 4−phase) in order to further optimize the filtering effect of the booster and lower the total application BOM cost for higher power. Thanks to the SPI programmability, one single hardware configuration can support various application platforms.
PRODUCT PROPERTIES
|
Mfr
|
onsemi
|
|
Series
|
-
|
|
Product Status
|
Active
|
|
Type
|
DC DC Controller
|
|
Topology
|
Step-Up (Boost)
|
|
Internal Switch(s)
|
No
|
|
Number of Outputs
|
1
|
|
Voltage - Supply (Min)
|
5V
|
|
Voltage - Supply (Max)
|
30V
|
|
Voltage - Output
|
0.4V
|
|
Current - Output / Channel
|
50mA
|
|
Frequency
|
10MHz
|
|
Dimming
|
PWM
|
|
Applications
|
Automotive
|
|
Operating Temperature
|
-40°C ~ 150°C (TJ)
|
|
Mounting Type
|
Surface Mount
|
|
Package / Case
|
24-VFQFN Exposed Pad
|
|
Supplier Device Package
|
24-QFN (4x4)
|
|
Base Product Number
|
NCV78702
|
