| Place of Origin: | China |
| Brand Name: | TI |
| Certification: | ISO9001 |
| Model Number: | TPS2062CDGNR |
| Minimum Order Quantity: | >=5pcs |
|---|---|
| Price: | $0.99 |
| Packaging Details: | Original factory sealed packing with standard types: tube,tray,tape and reel,box,bag packing. |
| Delivery Time: | 2-3days |
| Payment Terms: | L/C, T/T, D/A, D/P, Western Union, MoneyGram |
| Supply Ability: | 80000 Acre/Acres per Day+pcs+1-2days |
| Description: | Power Switch/Driver 1:2 N-Channel 1A 8-HVSSOP | Mounting Type: | Surface Mount |
|---|---|---|---|
| Operating Temperature: | -40°C ~ 125°C | Package / Case: | 8-TSSOP |
| Voltage - Supply: | 4.5V ~ 5.5V | Amplifier Type: | Active |
| Base Product Number: | TPS2062 | ||
| High Light: | TPS2062CDGNR IC,N CHAN Power Switch Ic |
||
PRODUCT DESCRIPTION
Part number TPS2062CDGNR is manufactured by TI Technologies and distributed by Stjk. As one of the leading distributors of electronic products, we carry many electronic components from the world's top manufacturers.
For more information on TPS2062CDGNR detailed specifications, quotations, lead times, payment terms and more, please do not hesitate to contact us. In order to process your enquiry, please add the quantity TPS2062CDGNR to your message. Send an email to stjkelec@hotmail.com for a quote now.
PRODUCT PROPERTIES
|
Product Status
|
Active
|
|
Switch Type
|
General Purpose
|
|
Number of Outputs
|
2
|
|
Ratio - Input:Output
|
1:2
|
|
Output Configuration
|
High Side
|
|
Output Type
|
N-Channel
|
|
Interface
|
On/Off
|
|
Voltage - Load
|
4.5V ~ 5.5V
|
|
Voltage - Supply (Vcc/Vdd)
|
Not Required
|
|
Current - Output (Max)
|
1A
|
|
Rds On (Typ)
|
70mOhm
|
|
Input Type
|
Non-Inverting
|
|
Features
|
Load Discharge, Status Flag
|
|
Fault Protection
|
Current Limiting (Fixed), Over Temperature, Reverse Current, UVLO
|
|
Operating Temperature
|
-40°C ~ 125°C (TJ)
|
|
Mounting Type
|
Surface Mount
|
|
Supplier Device Package
|
8-HVSSOP
|
|
Package / Case
|
8-TSSOP, 8-MSOP (0.118", 3.00mm Width) Exposed Pad
|
|
Base Product Number
|
TPS2062
|
