STJK(HK) ELECTRONICS CO.,LIMITED
Quality first, reputation first, service first, customers first.
 |
| Place of Origin: | China,GuangDong,ShenZhen |
| Brand Name: | Infineon Technologies |
| Certification: | ISO9001 |
| Model Number: | BSS138W H6327 |
| Minimum Order Quantity: | >=20pcs |
|---|---|
| Price: | $5.5 |
| Packaging Details: | Tape & Reel (TR) Cut Tape (CT) Digi-Reel |
| Delivery Time: | 2-5days |
| Payment Terms: | T/T, Western Union, D/P, D/A, MoneyGram, L/C |
| Supply Ability: | 10000 Acre/Acres per Day+pcs+1-2days |
| Description: | MOSFET N-CH 60V 280MA SOT323-3 | Package / Case: | SC-70, SOT-323 |
|---|---|---|---|
| Mounting Type: | Surface Mount | Operating Temperature: | -55°C ~ 150°C (TJ) |
| Voltage - Supply: | 4.5V, 10V | FET Type: | N-Channel |
| Product Status: | Active | Base Product Number: | BSS138 |
PRODUCT DESCRIPTION
Part number BSS138W H6327 is one of the products we sell. If you need BSS138W H6327 or its related products, please provide us with the product specifications, quantity and packaging requirements. It would be better to attach product pictures, and we will give you a quotation as soon as possible.
PRODUCT PROPERTIES
|
Product Status
|
Active
|
|
FET Type
|
N-Channel
|
|
Technology
|
MOSFET (Metal Oxide)
|
|
Drain to Source Voltage (Vdss)
|
60 V
|
|
Current - Continuous Drain (Id) @ 25°C
|
280mA (Ta)
|
|
Drive Voltage (Max Rds On, Min Rds On)
|
4.5V, 10V
|
|
Rds On (Max) @ Id, Vgs
|
3.5Ohm @ 200mA, 10V
|
|
Vgs(th) (Max) @ Id
|
1.4V @ 26µA
|
|
Gate Charge (Qg) (Max) @ Vgs
|
1.5 nC @ 10 V
|
|
Vgs (Max)
|
±20V
|
|
Input Capacitance (Ciss) (Max) @ Vds
|
43 pF @ 25 V
|
|
FET Feature
|
-
|
|
Power Dissipation (Max)
|
500mW (Ta)
|
|
Operating Temperature
|
-55°C ~ 150°C (TJ)
|
|
Mounting Type
|
Surface Mount
|
|
Supplier Device Package
|
PG-SOT323
|
|
Package / Case
|
SC-70, SOT-323
|
|
Base Product Number
|
BSS138
|
