| Model Number: | LT3065EMSE#PBF |
| Minimum Order Quantity: | >=20pcs |
|---|---|
| Price: | ￥0.99 |
| Packaging Details: | Original factory sealed packing with standard types: tube,tray,tape and reel,box,bag packing. Or request for your need. |
| Delivery Time: | 1-3work days |
| Payment Terms: | Escrow, L/C, D/A, MoneyGram |
| Supply Ability: | 35000 Acre/Acres per Day+pcs+1-2days |
| Description: | IC REG LIN POS ADJ 500MA 12MSOP | Operating Voltage:: | 0.6V ~40V |
|---|---|---|---|
| Operating Temperature:: | -40°C ~ 125°C | Product Status: | Active |
| PSRR: | 120Hz | Type: | Adjustable |
| Package / Case: | 12-TSSOP | Base Product Number: | LT3065 |
PRODUCT DESCRIPTION
TheLT®3065 Seriesaremicropower, lownoise, lowdropout voltage (LDO) linear regulators that operate over a 1.6V to 45V input voltage range. The devices supply 500mA of output current with a typical dropout voltage of 300mV.
A single external capacitor provides programmable low noise reference performance and output soft-start functionality. A single external resistor programs the LT3065’s current limit, accurate to ±10% over a wide input voltage and temperature range. A PWRGD flag indicates output regulation.
The LT3065 optimizes stability and transient response with low ESR ceramic capacitors, requiring a minimum of 3.3µF. Internalprotectioncircuitry includes currentlimiting with foldback, thermal limiting, reverse battery protection, reverse current protection and reverse output protection.
The LT3065 is available in fixed output voltages of 1.2V, 1.5V, 1.8V, 2.5V, 3.3V, and 5V, and as an adjustable device with an output voltage range from 0.6V to 40V. The LT3065 is available in the thermally-enhanced 10-lead 3mm × 3mm DFN and 12-lead MSOP packages.
PRODUCT PROPERTIES
|
Product Status
|
Active
|
|
Output Configuration
|
Positive
|
|
Output Type
|
Adjustable
|
|
Number of Regulators
|
1
|
|
Voltage - Input (Max)
|
45V
|
|
Voltage - Output (Min/Fixed)
|
0.6V
|
|
Voltage - Output (Max)
|
40V
|
|
Voltage Dropout (Max)
|
0.51V @ 500mA
|
|
Current - Output
|
500mA
|
|
Current - Quiescent (Iq)
|
110 µA
|
|
Current - Supply (Max)
|
25 mA
|
|
PSRR
|
85dB (120Hz)
|
|
Control Features
|
Current Limit, Enable, Power Good, Soft Start
|
|
Protection Features
|
Over Current, Over Temperature, Reverse Polarity
|
|
Operating Temperature
|
-40°C ~ 125°C
|
|
Mounting Type
|
Surface Mount
|
|
Package / Case
|
12-TSSOP (0.118", 3.00mm Width) Exposed Pad
|
|
Supplier Device Package
|
12-MSOP-EP
|
|
Base Product Number
|
LT3065
|
