| Place of Origin: | China,GuangDong |
| Brand Name: | Analog Devices Inc. |
| Certification: | ISO9001 |
| Model Number: | AD8021ARZ-REEL7 |
| Minimum Order Quantity: | >=5pcs |
|---|---|
| Price: | $3.89 |
| Packaging Details: | Original factory sealed packing with standard types: tube,tray,tape and reel,box,bag packing. Or request for your need. |
| Delivery Time: | 1-5work days |
| Payment Terms: | L/C, D/A, D/P, Western Union, T/T |
| Supply Ability: | 50000 Acre/Acres per Day+pcs+2-5days |
| Description: | IC VOLTAGE FEEDBACK 1 CIRC 8SOIC | Package / Case: | 8-SOIC |
|---|---|---|---|
| Mounting Type: | Surface Mount | Operating Temperature: | -40°C ~ 85°C |
| Voltage - Supply: | 4.5 V~ 24V | Type: | Voltage Feedback |
| Product Status: | Active | Base Product Number: | AD8021 |
PRODUCT DESCRIPTION
The AD8021 allows the user to choose the gain bandwidth product that best suits the application. With a single capacitor, the user can compensate the AD8021 for the desired gain with little trade-off in bandwidth.
The AD8021 is a well-behaved amplifier that settles to 0.01% in 23 ns for a 1 V step. It has a fast overload recovery of 50 ns. The AD8021 is stable over temperature with low input offset voltage drift and input bias current drift, 0.5 μV/°C and 10 nA/°C, respectively. The AD8021 is also capable of driving a 75 Ω line with ±3 V video signals.
The AD8021 is both technically superior and priced considerably less than comparable amps drawing much higher quiescent current. The AD8021 is a high speed, general-purpose amplifier, ideal for a wide variety of gain configurations and can be used throughout a signal processing chain and in control loops.
The AD8021 is available in both standard 8-lead SOIC and MSOP packages in the industrial temperature range of −40°C to +85°C.
PRODUCT PROPERTIES
|
Product Status
|
Active
|
|
Amplifier Type
|
Voltage Feedback
|
|
Number of Circuits
|
1
|
|
Output Type
|
-
|
|
Slew Rate
|
460V/µs
|
|
-3db Bandwidth
|
560 MHz
|
|
Current - Input Bias
|
7.5 µA
|
|
Voltage - Input Offset
|
400 µV
|
|
Current - Supply
|
7.8mA
|
|
Current - Output / Channel
|
70 mA
|
|
Voltage - Supply Span (Min)
|
4.5 V
|
|
Voltage - Supply Span (Max)
|
24 V
|
|
Operating Temperature
|
-40°C ~ 85°C
|
|
Mounting Type
|
Surface Mount
|
|
Package / Case
|
8-SOIC (0.154", 3.90mm Width)
|
|
Supplier Device Package
|
8-SOIC
|
|
Base Product Number
|
AD8021
|
