STJK(HK) ELECTRONICS CO.,LIMITED
Quality first, reputation first, service first, customers first.

|
| Place of Origin: | China,GuangDong |
| Brand Name: | Analog Devices Inc. |
| Certification: | ISO9001 |
| Model Number: | LTC3879IMSE#TRPBF |
| Minimum Order Quantity: | >=10pcs |
|---|---|
| Price: | $4.8 |
| Packaging Details: | Original factory sealed packing with standard types: tube,tray,tape and reel,box,bag packing. Or request for your need. |
| Delivery Time: | 1-5work days |
| Payment Terms: | Western Union, D/P, D/A, T/T |
| Supply Ability: | 60000 Acre/Acres per Day+pcs+2-3days |
| Description: | IC REG CTRLR BUCK 16MSOP | Package / Case: | 16-TFSOP |
|---|---|---|---|
| Mounting Type: | Surface Mount | Operating Temperature: | -40°C ~ 85°C (TA) |
| Voltage - Supply: | 4V ~ 38V | Type: | Transistor Driver |
| Product Status: | Active | Base Product Number: | LTC3879 |
PRODUCT DESCRIPTION
The LTC®3879 is a synchronous step-down switching regulator controller optimized for high switching frequency and fast transient response.
The constant on-time valley current mode architecture allows for a wide input range, including very low duty factor operation. No external sense resistor or slope compensation is required. System fl exibility is offered through a user-programmable soft-start pin and independent RUN pin.
The voltage ramping soft-start function can be programmed with a capacitor or made to track an external reference source. Operating frequency is set by an external resistor and compensated for variations in VIN to offer excellent line stability. Discontinuous mode operation provides high effi ciency during light load conditions.
A forced continuous control pin allows the user to reduce noise and RF interference. Safety features include output overvoltage protection and programmable current limit with foldback. The current limit is user programmable.
The LTC3879 allows operation from 4V to 38V at the input and from 0.6V to 90% VIN at the output. The LTC3879 is available in a small 16-pin thermally enhanced MSOP or 3mm × 3mm QFN packages.
PRODUCT PROPERTIES
|
Series
|
-
|
|
Product Status
|
Active
|
|
Output Type
|
Transistor Driver
|
|
Function
|
Step-Down
|
|
Output Configuration
|
Positive or Negative
|
|
Topology
|
Buck
|
|
Number of Outputs
|
1
|
|
Output Phases
|
1
|
|
Voltage - Supply (Vcc/Vdd)
|
4V ~ 38V
|
|
Frequency - Switching
|
-
|
|
Duty Cycle (Max)
|
-
|
|
Synchronous Rectifier
|
Yes
|
|
Clock Sync
|
No
|
|
Serial Interfaces
|
-
|
|
Control Features
|
Enable, Power Good, Soft Start, Tracking
|
|
Operating Temperature
|
-40°C ~ 85°C (TA)
|
|
Mounting Type
|
Surface Mount
|
|
Package / Case
|
16-TFSOP (0.118", 3.00mm Width) Exposed Pad
|
|
Supplier Device Package
|
16-MSOP-EP
|
|
Base Product Number
|
LTC3879
|
