STJK(HK) ELECTRONICS CO.,LIMITED
Quality first, reputation first, service first, customers first.

|
| Place of Origin: | China,GuangDong |
| Brand Name: | Analog Devices Inc. |
| Certification: | ISO9001 |
| Model Number: | LTC3851AHMSE#TRPBF |
| Minimum Order Quantity: | >=5pcs |
|---|---|
| Price: | $5.0 |
| Packaging Details: | Original factory sealed packing with standard types: tube,tray,tape and reel,box,bag packing. Or request for your need. |
| Delivery Time: | 2-4work days |
| Payment Terms: | L/C, D/A,Western Union, T/T |
| Supply Ability: | 40000 Acre/Acres per Day+pcs+2-3days |
| Description: | IC REG CTRLR BUCK 16MSOP | Package / Case: | 16-TFSOP |
|---|---|---|---|
| Mounting Type: | Surface Mount | Operating Temperature: | -40°C ~ 150°C (TJ) |
| Voltage - Supply: | 4V ~ 38V | Type: | Transistor Driver |
| Product Status: | Active | Base Product Number: | LTC3851 |
PRODUCT DESCRIPTION
The LTC®3851A is a high performance synchronous step-down switching regulator controller that drives an all N-channel synchronous power MOSFET stage. A constant frequency current mode architecture allows a phase-lockable frequency of up to 750kHz.
OPTI-LOOP compensation allows the transient response to be optimized over a wide range of output capacitance and ESR values. The LTC3851A features a precision 0.8V reference that is compatible with a wide 4V to 38V input supply range.
The TK/SS pin ramps the output voltage during start-up. Current foldback limits MOSFET heat dissipation during short-circuit conditions. The MODE/PLLIN pin selects among Burst Mode operation, pulse-skipping mode or continuous inductor current mode at light loads and allows the IC to be synchronized to an external clock.
The LTC3851A contains an improved PLL compared to the LTC3851. The LTC3851A-1 is a version with a power good output signal instead of adjustable current limit.
PRODUCT PROPERTIES
|
Product Status
|
Active
|
|
Output Type
|
Transistor Driver
|
|
Function
|
Step-Down
|
|
Output Configuration
|
Positive
|
|
Topology
|
Buck
|
|
Number of Outputs
|
1
|
|
Output Phases
|
1
|
|
Voltage - Supply (Vcc/Vdd)
|
4V ~ 38V
|
|
Frequency - Switching
|
235kHz ~ 750kHz
|
|
Duty Cycle (Max)
|
99%
|
|
Synchronous Rectifier
|
Yes
|
|
Clock Sync
|
No
|
|
Serial Interfaces
|
-
|
|
Control Features
|
Current Limit, Enable, Frequency Control, Soft Start, Tracking
|
|
Operating Temperature
|
-40°C ~ 150°C (TJ)
|
|
Mounting Type
|
Surface Mount
|
|
Package / Case
|
16-TFSOP (0.118", 3.00mm Width) Exposed Pad
|
|
Supplier Device Package
|
16-MSOP-EP
|
|
Base Product Number
|
LTC3851
|
