| Description: | IC REG BUCK ADJ 1A/1.5A DL 16DFN | Package / Case: | 16-DFN |
|---|---|---|---|
| Mounting Type: | Surface Mount | Operating Temperature: | -40°C ~ 85°C |
| Voltage - Supply: | 2.25V ~ 5.5V | Type: | Adjustable |
| Product Status: | Active | Base Product Number: | LTC3417 |
PRODUCT DESCRIPTION
The LTC®3417A-2 is a dual constant frequency, synchronous step-down DC/DC converter. Intended for medium power applications, it operates from a 2.25V to 5.5V input voltage range and has a constant programmable switching frequency, allowing the use of tiny, low cost capacitors and inductors 2mm or less in height.
Each output voltage is adjustable from 0.8V to 5V. Internal synchronous, low RDS(ON) power switches provide high effi ciency without the need for external Schottky diodes. A user selectable mode input allows the user to trade off ripple voltage for light load effi ciency. Burst Mode operation provides high effi ciency at light loads, while Pulse Skip mode provides low ripple noise at light loads. A phase mode pin allows the second channel to operate in-phase or 180° out-of-phase with respect to channel 1.
Out-of-phase operation produces lower RMS current on VIN and thus lower stress on the input capacitor. To further maximize battery life, the P-channel MOSFETs are turned on continuously in dropout (100% duty cycle) and both channels draw a total quiescent current of only 100μA. In shutdown, the device draws <1μA.
PRODUCT PROPERTIES
|
Product Status
|
Active
|
|
Function
|
Step-Down
|
|
Output Configuration
|
Positive
|
|
Topology
|
Buck
|
|
Output Type
|
Adjustable
|
|
Number of Outputs
|
2
|
|
Voltage - Input (Min)
|
2.25V
|
|
Voltage - Input (Max)
|
5.5V
|
|
Voltage - Output (Min/Fixed)
|
0.8V
|
|
Voltage - Output (Max)
|
5V
|
|
Current - Output
|
1A, 1.5A
|
|
Frequency - Switching
|
1.5MHz, 600kHz ~ 4MHz
|
|
Synchronous Rectifier
|
Yes
|
|
Operating Temperature
|
-40°C ~ 85°C (TA)
|
|
Mounting Type
|
Surface Mount
|
|
Package / Case
|
16-WFDFN Exposed Pad
|
|
Supplier Device Package
|
16-DFN (5x3)
|
|
Base Product Number
|
LTC3417
|
