1 Circuit Current Sense Amplifier Special Purpose Integrated Circuit 8-MSOP LT1999IMS8-20#TRPBF

1 Circuit Current Sense Amplifier Special Purpose Integrated Circuit 8-MSOP LT1999IMS8-20#TRPBF

  • 1 Circuit Current Sense Amplifier Special Purpose Integrated Circuit 8-MSOP LT1999IMS8-20#TRPBF
  • 1 Circuit Current Sense Amplifier Special Purpose Integrated Circuit 8-MSOP LT1999IMS8-20#TRPBF
  • 1 Circuit Current Sense Amplifier Special Purpose Integrated Circuit 8-MSOP LT1999IMS8-20#TRPBF
  • 1 Circuit Current Sense Amplifier Special Purpose Integrated Circuit 8-MSOP LT1999IMS8-20#TRPBF
  • 1 Circuit Current Sense Amplifier Special Purpose Integrated Circuit 8-MSOP LT1999IMS8-20#TRPBF
  • 1 Circuit Current Sense Amplifier Special Purpose Integrated Circuit 8-MSOP LT1999IMS8-20#TRPBF
1 Circuit Current Sense Amplifier Special Purpose Integrated Circuit 8-MSOP LT1999IMS8-20#TRPBF
Product Details:
Place of Origin: China,GuangDong
Brand Name: Analog Devices Inc.
Certification: ISO9001
Model Number: LT1999IMS8-20#TRPBF
Payment & Shipping Terms:
Minimum Order Quantity: >=50pcs
Price: $3.9
Packaging Details: Original factory sealed packing with standard types: tube,tray,tape and reel,box,bag packing. Or request for your need.
Delivery Time: 2-3work days
Payment Terms: T/T, Western Union, D/P, D/A, MoneyGram, L/C
Supply Ability: 50000 Acre/Acres per Day+pcs+2-7days
Contact Now
Detailed Product Description
Description: IC CURRENT SENSE 1 CIRCUIT 8MSOP Package / Case: 8-TSSOP, 8-MSOP
Mounting Type: Surface Mount Operating Temperature: -40°C ~ 85°C
Voltage - Supply: 4.5 V ~ 5.5V Type: Current Sense
Product Status: Active Base Product Number: LT1999

1 Circuit Current Sense Amplifier Special Purpose Integrated Circuit 8-MSOP LT1999IMS8-20#TRPBF



PRODUCT DESCRIPTION



The LT®1999 is a high speed precision current sense amplifier, designed to monitor bidirectional currents over a wide common mode range. The LT1999 is offered in three gain options: 10V/V, 20V/V, and 50V/V. The LT1999 senses current via an external resistive shunt and generates an output voltage, indicating both magnitude and direction of the sensed current.



The output voltage is referenced halfway between the supply voltage and ground, or an external voltage can be used to set the reference level. With a 2MHz bandwidth and a common mode input range of –5V to 80V, the LT1999 is suitable for monitoring currents in H-Bridge motor controls, switching power supplies, solenoid currents, and battery charge currents from full charge to depletion.



The LT1999 operates from an independent 5V supply and draws 1.55mA. A shutdown mode is provided for minimizing power consumption. The LT1999 is available in an 8-lead SOP, an 8-lead MSOP (original pinout), or an 8-lead pinout option engineered for FMEA.





PRODUCT PROPERTIES



Product Status
Active
Amplifier Type
Current Sense
Number of Circuits
1
Output Type
-
Slew Rate
3V/µs
-3db Bandwidth
2 MHz
Current - Input Bias
137.5 µA
Voltage - Input Offset
500 µV
Current - Supply
5.8mA
Voltage - Supply Span (Min)
4.5 V
Voltage - Supply Span (Max)
5.5 V
Operating Temperature
-40°C ~ 85°C
Mounting Type
Surface Mount
Package / Case
8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
Supplier Device Package
8-MSOP
Base Product Number
LT1999
