STJK(HK) ELECTRONICS CO.,LIMITED
Quality first, reputation first, service first, customers first.

|
| Place of Origin: | China,GuangDong,ShenZhen |
| Brand Name: | Infineon Technologies |
| Certification: | ISO9001 |
| Model Number: | IR3889MTRPBF |
| Minimum Order Quantity: | >=5pcs |
|---|---|
| Price: | $2.9 |
| Packaging Details: | Original factory sealed packing with standard types: tube,tray,tape and reel,box,bag packing. Or request for your need. |
| Delivery Time: | 2-5days |
| Payment Terms: | T/T, Western Union, D/P, D/A, , L/C |
| Supply Ability: | 20000 Acre/Acres per Day+pcs+2-3days |
| Description: | Buck Switching Regulator IC Positive Adjustable 0.8V 1 Output 30A 36-PowerVFQFN | Package / Case: | 36-PowerVFQFN |
|---|---|---|---|
| Mounting Type: | Surface Mount | Operating Temperature: | -40°C ~ 150°C (TJ) |
| Voltage - Supply: | 0.8V ~ 17V | Current - Output: | 30A |
| Product Status: | Active | Base Product Number: | IR3889 |
PRODUCT DESCRIPTION
The IR3889 is an easy-to-use, fully integrated dc - dc Buck regulator. The onboard PWM controller and OptiMOS™ FETs with integrated bootstrap diode make IR3889 a small footprint solution, providing high-efficient power delivery. Furthermore, it uses a fast Constant On-Time (COT) control scheme, which simplifies the design efforts and achieves fast control response.
The IR3889 has an internal low dropout voltage regulator, allowing operations with a single supply. It can also operate with an external bias supply, with an extended operating input voltage (PVin) range from 2.0 V to 17 V. The IR3889 is a versatile regulator, offering programmable switching frequency from 600 kHz to 2 MHz, four selectable current limits, four selectable soft-start time, Forced Continuous Conduction Mode (FCCM) and Diode Emulation Mode (DEM) operation.
It also features important protection functions, such as pre-bias start-up, thermally compensated current limit, over voltage and under voltage protection, and thermal shutdown to give required system level security in the event of fault conditions.
PRODUCT PROPERTIES
|
Product Status
|
Active
|
|
Function
|
Step-Down
|
|
Output Configuration
|
Positive
|
|
Topology
|
Buck
|
|
Output Type
|
Adjustable
|
|
Number of Outputs
|
1
|
|
Voltage - Input (Min)
|
2V
|
|
Voltage - Input (Max)
|
17V
|
|
Voltage - Output (Min/Fixed)
|
0.8V
|
|
Voltage - Output (Max)
|
17V
|
|
Current - Output
|
30A
|
|
Frequency - Switching
|
600kHz ~ 2MHz
|
|
Synchronous Rectifier
|
Yes
|
|
Operating Temperature
|
-40°C ~ 150°C (TJ)
|
|
Mounting Type
|
Surface Mount
|
|
Package / Case
|
36-PowerVFQFN
|
|
Supplier Device Package
|
PG-IQFN-36-2
|
|
Base Product Number
|
IR3889
|
Contact Person: Tom Guo
Tel: +8613822899993
