STJK(HK) ELECTRONICS CO.,LIMITED
Quality first, reputation first, service first, customers first.
 |
| Place of Origin: | China,GuangDong,ShenZhen |
| Brand Name: | Infineon Technologies |
| Certification: | ISO9001 |
| Model Number: | IR38164MTRPBF |
| Minimum Order Quantity: | >=5pcs |
|---|---|
| Price: | $2.9 |
| Packaging Details: | Tape & Reel (TR) Cut Tape (CT) Digi-Reel |
| Delivery Time: | 2-5work days |
| Payment Terms: | D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 80000 Acre/Acres per Day+pcs+2-7days |
| Description: | IC REG 24PQFN | Package / Case: | 24-PQFN |
|---|---|---|---|
| Mounting Type: | Surface Mount | Operating Temperature: | -40°C ~ 125°C (TJ) |
| Voltage - Supply: | 0.5V ~ 14V | Current - Output: | 30A |
| Product Status: | Active | Base Product Number: | IR38164 |
PRODUCT DESCRIPTION
The IR38164 OptiMOS™ IPOL is an easy to use, fully integrated and highly efficient dc-dc regulator with Intel SVID and I2C/PMBus™ interfaces. The on-chip PWM controller and co-packaged low duty cycle optimized MOSFETs make the device a space-efficient solution, providing accurate power delivery for low output voltage and high current applications that require an Intel SVID interface.
The IR38164 offers programmability of switching frequency, output voltage, and fault/warning thresholds and fault responses while operating over a wide input range. Providing flexibility as well as system level security in the event of fault conditions. The switching frequency is programmable from 500 kHz to 1.5 MHz for an optimum solution.
The on-chip sensors and ADC along with the SVID, I2C and PMBus™ make it easy to monitor and report input voltage, output voltage, output current and temperature.
PRODUCT PROPERTIES
|
Product Status
|
Active
|
|
Function
|
Step-Down
|
|
Output Configuration
|
Positive
|
|
Topology
|
Buck
|
|
Output Type
|
Adjustable
|
|
Number of Outputs
|
1
|
|
Voltage - Input (Min)
|
1.5V
|
|
Voltage - Input (Max)
|
16V
|
|
Voltage - Output (Min/Fixed)
|
0.5V
|
|
Voltage - Output (Max)
|
14V
|
|
Current - Output
|
30A
|
|
Frequency - Switching
|
500kHz ~ 1.5MHz
|
|
Synchronous Rectifier
|
Yes
|
|
Operating Temperature
|
-40°C ~ 125°C (TJ)
|
|
Mounting Type
|
Surface Mount
|
|
Package / Case
|
24-PowerVFQFN
|
|
Supplier Device Package
|
24-PQFN (5x7)
|
|
Base Product Number
|
IR38164
|
