STJK(HK) ELECTRONICS CO.,LIMITED
Quality first, reputation first, service first, customers first.

|
| Place of Origin: | China,GuangDong,ShenZhen |
| Brand Name: | Analog Devices Inc. |
| Certification: | ISO9001 |
| Model Number: | LTC3780IG#TRPBF |
| Minimum Order Quantity: | >=20pcs |
|---|---|
| Price: | ￥0.99 |
| Packaging Details: | Original factory sealed packing with standard types: tube,tray,tape and reel,box,bag packing. Or request for your need. |
| Delivery Time: | 1-3work days |
| Payment Terms: | Escrow, L/C, D/A, |
| Supply Ability: | 35000 Acre/Acres per Day+pcs+1-2days |
| Description: | IC REG CTRLR BUCK-BOOST 24SSOP | Operating Voltage:: | 4V ~ 30V |
|---|---|---|---|
| Operating Temperature:: | 0°C ~ 70°C | Product Status: | Active |
| -3db Bandwidth: | 200kHz ~ 400kHz | Type: | Transistor Driver |
| Package / Case: | 24-SSOP | Base Product Number: | LTC3780 |
PRODUCT DESCRIPTION
The LTC®3780 is a high performance buck-boost switching regulator controller that operates from input voltages above, below or equal to the output voltage. The constant frequency current mode architecture allows a phaselockable frequency of up to 400kHz.With a wide 4V to 30V (36V maximum) input and output range and seamless transfers between operating modes, the LTC3780 is ideal for automotive, telecom and battery-powered systems.
The operating mode of the controller is determined through the FCB pin. For boost operation, the FCB mode pin can select among Burst Mode® operation, discontinuous mode and forced continuous mode. During buck operation, the FCB mode pin can select among skip-cycle mode, discontinuous mode and forced continuous mode. Burst Mode operation and skip-cycle mode provide high efficiency operation at light loads while forced continuous mode and discontinuous mode operate at a constant frequency.
Fault protection is provided by an output overvoltage comparator and internal foldback current limiting. A power good output pin indicates when the output is within 7.5% of its designed set point.
PRODUCT PROPERTIES
|
Product Status
|
Active
|
|
Output Type
|
Transistor Driver
|
|
Function
|
Step-Up/Step-Down
|
|
Output Configuration
|
Positive
|
|
Topology
|
Buck-Boost
|
|
Number of Outputs
|
1
|
|
Output Phases
|
1
|
|
Voltage - Supply (Vcc/Vdd)
|
4V ~ 30V
|
|
Frequency - Switching
|
200kHz ~ 400kHz
|
|
Duty Cycle (Max)
|
99%
|
|
Synchronous Rectifier
|
Yes
|
|
Clock Sync
|
No
|
|
Serial Interfaces
|
-
|
|
Control Features
|
Current Limit, Enable, Power Good, Soft Start
|
|
Operating Temperature
|
-40°C ~ 125°C (TJ)
|
|
Mounting Type
|
Surface Mount
|
|
Package / Case
|
24-SSOP (0.209", 5.30mm Width)
|
|
Supplier Device Package
|
24-SSOP
|
|
Base Product Number
|
LTC3780
|
