STJK(HK) ELECTRONICS CO.,LIMITED
Quality first, reputation first, service first, customers first.
 |
| Place of Origin: | China,GuangDong,ShenZhen |
| Brand Name: | Analog Devices Inc. |
| Certification: | ISO9001 |
| Model Number: | AD5545BRUZ-REEL7 |
| Minimum Order Quantity: | >=10pcs |
|---|---|
| Price: | ￥2.49 |
| Packaging Details: | Tape & Reel (TR) Cut Tape (CT) Digi-Reel |
| Delivery Time: | 2-3work days |
| Payment Terms: | T/T, D/A, L/C, D/P, Western Union, MoneyGram |
| Supply Ability: | 60000 Acre/Acres per Day+pcs+2-4days |
| Description: | IC DAC 16BIT A-OUT 16TSSOP | Operating Voltage:: | 5V |
|---|---|---|---|
| Operating Temperature:: | -40°C ~ 85°C | Product Status: | Active |
| Number Of Bits: | 16 | Type: | Current - Unbuffered |
| Package / Case: | 16-TSSOP | Base Product Number: | AD5545 |
PRODUCT DESCRIPTION
The AD5545/AD5555 are 16-bit/14-bit, current-output, digitalto-analog converters designed to operate from a 4.5 V to 5.5 V supply range. An external reference is needed to establish the full-scale output-current.
An internal feedback resistor (RFB) enhances the resistance and temperature tracking when combined with an external op amp to complete the I-to-V conversion.
A serial data interface offers high speed, 3-wire microcontroller compatible inputs using serial data in (SDI), clock (CLK), and chip select (CS). Additional LDAC function allows simultaneous update operation. The internal reset logic allows power-on preset and dynamic reset at either zero or midscale, depending on the state of the MSB pin.
The AD5545/AD5555 are packaged in the compact TSSOP-16 package and can be operated from −40°C to +85°C.
PRODUCT PROPERTIES
|
Product Status
|
Active
|
|
Number of Bits
|
16
|
|
Number of D/A Converters
|
2
|
|
Settling Time
|
500ns (Typ)
|
|
Output Type
|
Current - Unbuffered
|
|
Differential Output
|
No
|
|
Data Interface
|
SPI
|
|
Reference Type
|
External
|
|
Voltage - Supply, Analog
|
5V
|
|
Voltage - Supply, Digital
|
5V
|
|
INL/DNL (LSB)
|
±2 (Max), ±1 (Max)
|
|
Architecture
|
R-2R
|
|
Operating Temperature
|
-40°C ~ 85°C
|
|
Package / Case
|
16-TSSOP (0.173", 4.40mm Width)
|
|
Supplier Device Package
|
16-TSSOP
|
|
Mounting Type
|
Surface Mount
|
|
Base Product Number
|
AD5545
|
