STJK(HK) ELECTRONICS CO.,LIMITED
Quality first, reputation first, service first, customers first.
 |
| Place of Origin: | China,GuangDong |
| Brand Name: | TE Connectivity Potter & Brumfield Relays |
| Certification: | ISO9001 |
| Model Number: | LTC4311CSC6#TRPBF |
| Minimum Order Quantity: | >=20pcs |
|---|---|
| Price: | $3.09 |
| Packaging Details: | Tape & Reel；Cut Tape；Digi-Reel |
| Delivery Time: | 2-5days |
| Payment Terms: | Escrow, L/C, D/A, D/P, T/T |
| Supply Ability: | 40000 Acre/Acres per Day+pcs+1-2days |
| Detailed Description: | IC ACCELERATOR I2C 1CH SC70-6 | Operating Temperature:: | 0°C ~ 70°C |
|---|---|---|---|
| Voltage - Supply: | 1.6V ~ 5.5V | Data Rate (Max): | 400kHz |
| Current - Supply: | 200µA | Product Status: | Active |
| Package / Case: | 6-TSSOP, SC-88, SOT-363 | Base Product Number: | LTC4311 |
| High Light: | Electronic Components Relays 1Channel,Electronic Components Relays 400kHz,LTC4311CSC6#TRPBF Relays |
||
PRODUCT DESCRIPTION
The LTC®4311 is a dual I2C active pull-up designed to enhance data transmission speed and reliability for bus loading conditions well beyond the 400pF I2C specifi cation limit. The LTC4311 operates at supply voltages from 1.6V to 5.5V and is also compatible with SMBus.
The LTC4311 allows multiple device connections or a longer, more capacitive interconnect, without compromising slew rates or bus performance, by using two slew limited pull-up currents.
During positive bus transitions, the LTC4311 provides slew limited pull-up currents to quickly slew the I2C or SMBus lines to the bus pull-up voltage. During negative transitions or steady DC levels, the currents are disabled to improve negative slew rate, and improve low state noise margins. An auto detect standby mode reduces supply current if both SCL and SDA are high. When disabled, the LTC4311 goes into low (<5μA) current shutdown.
The LTC4311 is available in the 2mm × 2mm × 0.75mm DFN, and SC70 packages.
PRODUCT PROPERTIES
|
Product Status
|
Active
|
|
Type
|
Accelerator
|
|
Applications
|
I²C
|
|
Input
|
2-Wire Bus
|
|
Output
|
2-Wire Bus
|
|
Data Rate (Max)
|
400kHz
|
|
Number of Channels
|
1
|
|
Delay Time
|
-
|
|
Signal Conditioning
|
-
|
|
Voltage - Supply
|
1.6V ~ 5.5V
|
|
Current - Supply
|
200µA
|
|
Operating Temperature
|
0°C ~ 70°C
|
|
Mounting Type
|
Surface Mount
|
|
Package / Case
|
6-TSSOP, SC-88, SOT-363
|
|
Supplier Device Package
|
SC-70-6
|
|
Base Product Number
|
LTC4311
|
