CPLD 144MC 7.5NS Programmable IC Chip 100TQFP XC95144XL-7TQ100C Wholesaler

IC CPLD 144MC 7.5NS 100TQFP XC95144XL-7TQ100C In System Programmable IC Chip

List of hot parts number: IC list 0913.pdf

PRODUCT DESCRIPTION

The XC95144XL-7TQ100C is an integrated circuit (IC) belonging to the Xilinx CoolRunner XPLA3 family. It is a field-programmable gate array (FPGA) specifically designed for low-power applications.

Here are some key features of the XC95144XL-7TQ100C IC:

1. Logic Cells: It contains 144 macrocells or logic cells, which are programmable building blocks used to implement digital logic functions.

2. Input/Output Pins: The IC has a total of 100 pins in a TQFP (Thin Quad Flat Pack) package. These pins are used for input and output connections to external devices or circuitry.

3. Speed Grade: The "-7" in the part number indicates that this IC is rated for a maximum operating frequency of 7 MHz.

4. Power Supply: The XC95144XL-7TQ100C operates with a supply voltage range of 3.3V, making it suitable for low-power applications.

5. Configuration: The IC can be configured using the Xilinx iMPACT software, which allows users to program the device to implement their desired logic functions.

6. I/O Standards: It supports various I/O standards such as LVTTL (Low Voltage TTL) and LVCMOS (Low Voltage CMOS), making it compatible with a wide range of digital systems.

7. Other Features: The XC95144XL-7TQ100C IC also includes features like on-chip clock management, programmable pull-up resistors, and JTAG boundary scan support.

Overall, the XC95144XL-7TQ100C IC is a versatile FPGA that offers low-power consumption and provides programmable logic resources for implementing custom digital circuits in various applications.

PRODUCT PROPERTIES
