STJK(HK) ELECTRONICS CO.,LIMITED
Quality first, reputation first, service first, customers first.
 |
| Place of Origin: | China |
| Brand Name: | Texas Instruments |
| Certification: | ISO9001 |
| Model Number: | LM5025AMTC |
| Minimum Order Quantity: | >=2pcs |
|---|---|
| Price: | $1.99 |
| Packaging Details: | Tape & Reel；Cut Tape；Digi-Reel |
| Delivery Time: | 2-3days |
| Payment Terms: | L/C, T/T, D/A, D/P, Western Union, |
| Supply Ability: | 30000 Acre/Acres per Day+pcs+1-2days |
| Description: | IC REG CTRLR FWRD CONV 16TSSOP | Mounting Type: | Surface Mount |
|---|---|---|---|
| Operating Temperature: | -40°C ~ 125°C | Package / Case: | TSSOP |
| Voltage - Supply: | 8V ~ 15V | Type: | Transistor Driver |
| Topology: | Forward Converter | Product Status: | Active |
| Base Product Number: | LM5025 | ||
| Highlight: | LM5025AMTC DC DC Step Up IC,6-TSSOP DC DC Step Up IC |
||
PRODUCT DESCRIPTION
Part number LM5025AMTC is manufactured by Texas Instruments and distributed by Stjk. As one of the leading distributors of electronic products, we carry many electronic components from the world's top manufacturers.
For more information on LM5025AMTC detailed specifications, quotations, lead times, payment terms and more, please do not hesitate to contact us. In order to process your enquiry, please add the quantity LM5025AMTC to your message. Send an email to stjkelec@hotmail.com for a quote now.
PRODUCT PROPERTIES
|
Output Type
|
Transistor Driver
|
|
Function
|
Step-Up/Step-Down
|
|
Output Configuration
|
Positive, Isolation Capable
|
|
Topology
|
Forward Converter
|
|
Number of Outputs
|
2
|
|
Output Phases
|
1
|
|
Voltage - Supply (Vcc/Vdd)
|
8V ~ 15V
|
|
Frequency - Switching
|
200kHz ~ 580kHz
|
|
Duty Cycle (Max)
|
80%
|
|
Synchronous Rectifier
|
No
|
|
Clock Sync
|
Yes
|
|
Serial Interfaces
|
-
|
|
Control Features
|
Dead Time Control, Frequency Control, Ramp, Soft Start
|
|
Operating Temperature
|
-40°C ~ 125°C (TJ)
|
|
Mounting Type
|
Surface Mount
|
|
Package / Case
|
16-TSSOP (0.173", 4.40mm Width)
|
|
Supplier Device Package
|
16-TSSOP
|
|
Base Product Number
|
LM5025
|
Contact Person: Tom Guo
Tel: +8613822899993
